- Robertson Cold Rolling Mill
The Robertson Cold Rolling Mill is a 4 Hi Universal Cold Rolling Mill of 1540 mm width with an input gauge of 7 mm, an output of .165 mm and a maximum speed of 280 m/min. The mill has been upgraded for speed, Auto Shape Control / Auto Gauge Control & higher coil density (from 3.2 kg/mm max). At time of installation in Jindal India Limited, the mill has been supplied with new electrics & drives by Siemens.
|
| Type |
4 Hi Universal |
| Width |
1540 mm max |
| Speed |
280 m/min max |
| Max. input gauge |
7 mm in Soft temper |
| Min output gauge |
0.165 mm |
| Coil size |
3.0 kg/mm max |
| Spool size |
530 mm x 1270 mm |
|
|
The Spidem Roughing Mill is a 4 Hi Universal Foil Mill with an input gauge of 0.7 mm & output of 9 microns (9 microns x 2 pack rolled) and a maximum speed of 900 m/min. The mill had been continuously upgraded for speed, auto shape control gauge control & higher coil density (from 3 kg/mm to 6 kg/mm). At time of installation in Jindal India Limited, the mill has been supplied with new electrics & drives by Siemens.
|
| Type |
4 Hi Universal |
| Width |
1100 mm max |
| Speed |
900 m/min max |
| Max. input gauge |
0.70mm in Soft temper, 0.30 mm in H14 temper |
| Min output gauge |
18 microns, 9 microns x 2 pack rolled |
| Coil size |
6kg/mm max |
| Spool size |
350mm x 1550 mm, 260 mm x 1220 mm |
|
|
The Achenbach Finishing Mill is essentially a Finishing Mill with capability to go down to 7 microns. It has a maximum rolling sped of 1000 m/min & is also equipped with auto gauge & new Siemens electrics & drives. The mill is extremely compact as is to be expected from a leading mill designer like Achenbach Buschhütten.
| Type |
4 Hi, Finishing |
| Width |
1100 mm max |
| Speed |
1000 m/min max |
| Max. input gauge |
0.15 mm |
| Min output gauge |
7 microns x 2 pack rolled |
| Coil size |
3kg/mm max |
| Spool size |
260 mm x 1220 mm |
|
|
Doubler has been provided for pairing of coils in preparation for pack rolling. Off line doubling helps to improve mill productivity by reducing coil change time in the pack-rolling pass.
| Type |
4 Hi, Finishing |
| Width |
1100 mm max |
| Speed |
600 m/min max |
| Max gauge |
30 microns x 2 |
| Min gauge |
14 microns x 2 |
| Max Coil size |
3kg/mm (1215 mm) |
| Spool size |
260 mm x 1220 mm |
|
|
- Schmutz & Kampf Separators
The Schmutz & Kampf Separators have a capability to slit & trim foil in the gauge range of 6 microns to 30 microns on 75 mm or 150 mm cores. The Kampf machine is state of art with capability to slit and separate 6-micron foil.
| Width |
1400 mm max |
| Foil gauge |
2 x 7 mic to 2 x 30 mic |
| Speed |
800 m/min max |
| Coil OD |
1500 mm max n unwind |
| Spools (unwind) |
260 OD x 1220 mm, 350 OD x 1550 mm |
| Rewinds |
Max 610 mm OD, core 150 mm |
|
|
| Width |
1050 mm max |
| Foil gauge |
2 x 6 mic to 2 x 50 mic |
| Speed |
1200 m/min max at 150mm ID core 700 m/min at 76.2 mm ID core |
| Coil OD (unwind) |
1215 mm |
| Spools (unwind) |
260 OD x 1220 mm, 350 OD x 1550 mm |
| Rewinds |
760 mm max OD, core 150 mm ID |
|
|
- Annealing furnaces (3 nos)
Annealing Furnaces have been supplied by Thermal Systems Chennai, leading manufacturers of annealing furnaces in India.The company has procured three number of 12 ton furnaces.
The capacities of individual machines have been well balanced so as to deliver around 5000 tons of light gauge bare foil (7-9 microns) per year.
| Loading weight |
12 tons |
| Max temp |
400 deg C |
| Max width of coil |
1100 mm |
|
|
The company has also procured a new state of the art roll grinding machine from Maschinenfabrik Herkules Germany. The Monolith type grinder is based on a hydrodynamic lubrication system and is very stable also guaranteeing the best available surface finish.
| Model |
WS 450 KL x 3500 CNC Monolith™ |
| Wheel size |
750 x 80 (100) x 305 mm |
| Roll diameter max./min. |
620/200 mm |
| Overall roll length max |
3250 mm |
| Max. roll weight |
5000 kgs (approx.) |
|
|
|
|
|
|
| | | |
|
|
|
